1. Application of the equipment:
This machine is specially designed to simulate a single product by the impact of falling or transportation process， which can evaluate the damage of the product. Sample to do a free mode or a controlled directional way to drop， test products vulnerable parts， side， side.
2. Device specification:
|
Model No. |
MC-720C |
MC-720NC |
|
Applicable sample |
Mobile phone |
Laptop |
|
Max. sample weight |
2kg |
5kg |
|
Drop mode |
Free fall + Controlled directional drop |
|
|
Drop height range |
30~180cm |
|
|
Acceleration measurement |
Yes |
|
|
Sample clamping way |
Edge， angle， surface |
|
|
The drive system |
AC servo motor+Reducer
|
|
|
Transmission mechanism |
High Accuracy of Ball Screw |
|
|
Device weight |
300kg |
1000kg |
|
Power supply |
AC220V/50HZ or AC110V/60HZ |
|
