1. Device introduction：
This machine is suitable for lens， plastic， ceramics， acrylic， glass fiber and other materials to withstand certain quality steel ball impact. To verify its fastness test.
1. Device specification：
|
Model no. |
BIT-004A |
|
Impact steel ball weight |
50g，110g，250g，500g or customized |
|
Impact height |
200-1500mm |
|
Height resolution |
0.01mm |
|
Anti-secondary impact device |
Yes |
|
Laser infrared alignment device |
Yes |
|
Automatic lifting drive for drop height |
Yes |
|
impact table |
15mm steel plate |
|
Machine size |
L60*50*H190cm |
|
Device weight |
200kg |
|
Power supply |
AC220V/50HZ or AC110V/60HZ |
|
Air source |
More than 2kgf |
